WireGuard – Secret Path In The Shades

Your Virtual Private Network isn’t there to watch geo-blocked content.
Once VPNs were used to connect networks, like remote offices of a company.
Today they protect your information and privacy.
This is why your VPN isn’t an optional tool anymore.
It’s your shield against the unwanted attention and passive monitoring.

Without a VPN your ISP can see a lot:

• your browsing habits
• your downloads
• the used protocols

They don’t see your data. They see patterns. They draw the map.

With a consumer VPN you shift your trust to your VPN provider.
If you host your own VPN service – you put your trust in yourself and your hosting provider.

Guard Your Wires

WireGuard is a modern VPN protocol.
It’s simple, fast and secure and it’s part of the Linux kernel.

Smaller codebase means easier audits.

Server Installation and Configuration

Install the wireguard package with your package manager:

sudo apt install wireguard

Generate the server keys:

wg genkey > server_private.key
wg pubkey < server_private.key > server_public.key
sudo mv *.key /etc/wireguard/

Protect the keys with hardened permissions:

sudo chmod 400 /etc/wireguard/{server_private.key,server_public.key}
sudo chown root:root /etc/wireguard/{server_private.key,server_public.key}

In the following examples:

• Replace the IP address with your IP.
• Replace the interface with your LAN interface.

Enable the local IP forwarding:

echo "net.ipv4.ip_forward=1" | sudo tee /etc/sysctl.d/wireguard.conf
sudo sysctl --system

In the /etc/ufw/sysctl.conf:

net.ipv4.ip_forward=1

In the /etc/ufw/before.rules before the *filter line:

*nat
:POSTROUTING ACCEPT [0:0]
-A POSTROUTING -s 10.20.20.0/24 -o enp1s0 -j MASQUERADE
COMMIT

Allow the routing in UFW:

sudo ufw route allow in on wg0 out on enp1s0
sudo ufw allow 51820/udp

Reload the UFW configuration:

sudo ufw disable
sudo ufw enable

WireGuard server configuration:

Minimal server configuration /etc/wireguard/wg0.conf.

# Server configuration
[Interface]
PrivateKey = <server_private_key>
Address = 10.20.20.1/24
ListenPort = 51820
SaveConfig = false
# Client's config
[Peer]
PublicKey = e2V40zdPiX43lqOamcoEI8J10uKaXWBeKwf+spWDWgc=
AllowedIPs = 10.20.20.2/32

Harden the file permissions:

sudo chmod 600 /etc/wireguard/wg0.conf

Start and enable the service:

sudo systemctl enable wg-quick@wg0
sudo systemctl start wg-quick@wg0

Verify the service:

sudo systemctl status wg-quick@wg0.service

Client Installation and Configuration

Install the wireguard package on the client machine as well.
Generate the key pair as you did on the server.
Don’t forget to harden their permissions.

Install the resolvconf package (optional on some systems):

sudo apt install resolvconf

WireGuard client configuration.

Minimal client config in /etc/wireguard/wg-ds.conf:

# Client's configuration
[Interface]
PrivateKey = <client_private_key>
Address = 10.20.20.2/32
SaveConfig = true
# Server's configuration
[Peer]
PublicKey = tInj/aAAZIkv8RWzAyXq5ngbO9OUPz+Fkbog7LkgQzQ=
Endpoint = <server_ip>:51820
AllowedIPs = 10.20.20.0/24, 192.168.100.0/24
PersistentKeepalive = 25

PersistentKeepalive is crucial for services behind NAT.

Don’t forget the hardening:

sudo chmod 600 /etc/wireguard/wg-ds.conf

Bring up the connection:

sudo wg-quick up wg-ds

Verify it:

sudo wg show

Break down the connection if you don’t need it:

sudo wg-quick down wg-ds

Final Thoughts

This configuration protects your browsing only between the client and the server.
What leaves the server is visible to third parties.
The trace leads back to the server – then to you.

Your VPN is not anonymity.
It’s your elevated privacy.
